Circuit:SPST Current rating:100mA
Voltage rating: 50VDC
Dielectric withstanding voltage :1000VAC for 1 minute
Contact resistance:50mΩ Max
Insulation resistance:100MΩ Min
Travel:1. 8mm±0.4mm
Operating Force:900±200gf
Mechanical life:30,000 cycles Min
Electric life:30,000 cycles Min
Solder specifications:260° C for 5 seconds
Function:Momentary
Operating temperature: -55° C~ +125° C
Sealing: Front-IP68,Back-IP65.
